CAPACITY |
|
GCL 60 |
GCL 100 |
GCL 150 |
|
Max. swing over bed |
mm |
350 |
400 |
400 |
|
Max. turning length |
mm |
150 |
200 |
200 |
|
Max. job swing dia. |
mm |
150 |
200 |
200 |
|
Std. turning dia. |
mm |
60 |
100 |
150 |
|
Chunk size |
mm |
135 |
165 |
200 |
|
MAIN SPINDLE |
|
|
|
|
|
Spindle motor power |
kw |
3.7 |
3.7/5.5 |
5.5/7.5 |
|
Spindle bore |
mm |
35 |
40 |
45 |
|
Spindle nose |
m/min |
A24 |
A25 |
A25/A26 |
|
Spindle speed(inf. variable) |
rpm |
3000 |
3000 |
3000 |
|
No. of tools for std. job dia range |
nos. |
3 |
3 |
3 |
|
Max. boring bar capacity |
mm |
25 |
32 |
32 |
|
Tool size (cross sectional) |
mm |
20x20 |
20x20 |
20x20 |
|
Cnc system |
make |
siemens/fanuc |
siemens/fanuc |
siemens/fanuc |
|
Feed rates |
|
|
|
|
|
Rapid traverse x'-axis |
mt/min |
20 |
20 |
20 |
|
Rapid traverse z'-axis |
mt/min |
20 |
20 |
20 |
|
Dimensions |
|
|
|
|
|
Machine weight (approx) |
kg |
2000 |
2400 |
2800 |
|
Machine dimension (approx) |
|
|
|
|
|
Length |
mm |
1800 |
2000 |
2200 |
|
Width |
mm |
1250 |
1400 |
1450 |
|
Height |
mm |
1500 |
1600 |
1600 |
Hydraulic Chuck & Closed Cylinder, One set of soft jaws, Hydraulic Power Pack, Coolant Supply Equipment, Centralized Lubrication equipment, Work light, Foot Switch, Linear tool holder blocks 2 Turning holder Block, Boring holder block, Set of manuals or CD.
Turret, Chip Conveyor, Coolant gun, Panel air Conditioner, Hollow Clamping Cylinder
