Shearing Machine Upto 4mm Thickness

Dimensions	Size	GSM-1250	GSM-1500	GSM-2000	GSM-2500	GSM-3000
Shearing Length	mm	1250	1500	2000	2500	3000
Shearing Capacity	mm	4	4	4	4	4
Power Required	HP	5	7.5	7.5	10	10
	RPM	1440	1440	1440	1440	1440
No.Of Strokes Per Minute	Nos.	55	55	50	50	50
Max. Back Gauge Adjustment	mm	450	450	550	550	550
Size Of Blade(Blade Segment)	mm	1270 x 62 x 14	1525 x 62 x 14	1016 x 62 x 14	1270 x 62 x 14	1525 x 62 x 14
No.Of Blades	Pcs.	2	2	4	4	4
Length Of Cut in One Stroke	mm	1250	1500	2000	2500	3000
Approx.Floor Area Required/Length x Width x Height	mm	2550 x 1550 x 1500	2800 x 1550 x 1500	3300 x 1550 x 1500	3800 x 1550 x 1500	4400 x 1550 x 1500
